Shakun

ECOTEK ^R

HFFR/ ZHFR Compound

Halogen Free Flame Retardant/Zero Halogen Flame Retardant Polyolefin Based Insulation and Sheathing Compounds For Wire and Cable Application.

HFFR (THERMOPLASTIC) - INSULATION

HFFR (THERMOPLASTIC) - GENERAL PURPOSE SHEATHING

HFFR (THERMOPLASTIC) - HIGH PERFORMANCE SHEATHING

HFFR (THERMOPLASTIC) - BEDDING

HFFR OPTIC FIBRE - OFC

HFFR (SILANE CROSS LINKABLE)

HFFR (HIGH FLAME RETARDANCY / HIGH CHAR)

HFFR (E-BEAM COMPOUND FOR SOLAR CABLE)

Grade	Description	Standard	Application
SPL-ZHFR-3500 IS	Insulation Compound	IS-17048, Type HFl-TP-70 IEC - 60332-1 & IEC - 60332-2	Building Wire
SPL-ZHFR-3500H	High Line Speed Insulation Compound	EN -50363-7:2005 Type TI 6 & TI 7 , IEC - 60332-1 & IEC - 60332-2 , NBR 13248	Building Wire
SPL-ZHFR-3500Q	High LOI (35%) Insulation Compound	EN -50363-7:2005, Type Tl 7, IEC - 60332-1, IEC - 60332-2	Building Wire & FTTH
asdada	sdadadas	adsadad	adasd
All Ecotek grades are RoHS and REACH compliant

FRTEK ^R

FR/FRLS Compound

PVC Based Flame Retardant / Flame Retardant Low Smoke Sheathing Compounds For Wire and Cable Application.

PVC FR/FRLS OIL RESISTANCE COMPOUNDS

PVC FRLS HIGH PERFORMANCE OIL RESISTANCE COMPOUNDS

Grade	Description	Standard	Application
SPL-AFOSR*	Oil resistance 100Â°C/24 hrs High-Performance Jacketing	BS-7655 Type9 ,IEC60502 Type ST2, IEC -60332-3 CAT-C	AT/AR, Oil & UV Resistance Sheathing for Control Cables
SPL-FR-TM53	OIL RESISTANCE Sheathing / Jacketing Application RoHS Compliance	EN 50290-2-22 Type TM53	RoHS, Oil & Heat Resistant, Cables, 70Â°C for 4 hrs
SPL-105FROR / 90 RoHS	105Â°C Oil Resistant Flame Retardant RoHS Compliance	EN 50363-3 :2005 Type Tl3, EN50363-4-1 :2005 Type TM3	Heat Resistant, Oil Resistance, Flame Retardant Cable
SPL-FRLS-206*	OIL RESISTANCE Sheathing / Jacketing Application	IEC - 60502 & IS 5831 Type ST2 IEC - 60332-3 CAT C	Oil Resistance 70Â°C for 4 hrs Sheathing for Control Cables
tesbro	tez	yesysusu	yes
* Available in RoHS version also.

VINYLTEK ^R

PVC/TPR Automotive Compound

PVC Based Insulation/Sheathing FR / FRLS Compounds / Thermoplastic Rubber Based Compounds and Automotive Cable Compounds.

AUTOMOTIVE COMPOUNDS

TPR COMPOUNDS

HEAT RESISTANT PVC COMPOUND (UL RECOGNISED)

HEAT RESISTANT PVC/FR/OIL RESISTANCE COMPOUNDS

PVC / FR (FLAME RETARDANT) - INSULATION

PVC / FR (FLAME RETARDANT) - GENERAL PURPOSE SHEATHING

PVC / FR (FLAME RETARDANT) - HIGH LOI SHEATHING

PVC ( FOR LOW TEMPERATURE APPLICATION ) COMPOUNDS

PVC FRLS (FLAME RETARDANT LOW SMOKE) COMPOUNDS

Grade	Description	Standard	Application
SPL-VTEK-2213	RoHS Compliance Automotive Cable Compound	AVS/AVSS as per JASO D 611, Temp Rating :-40°C to 80°C	Thin Wall Insulation for Automotive Cable
SPL-VTEK-2213E	RoHS Compliance Automotive Cable Compound with JEC TEC Air Oven	AVS/AVSS as per JASO D 611,JIS K 7212 Temp Rating : -40°C to 80°C	Thin Wall Insulation for Automotive Cable
SPL-VTEK-611	RoHS Compliance Automotive Cable Compound (T2 Battery)	Class B as per ISO 6722, Temp Rating :- 40°C to 105°C	Automotive Cable for 6.0 sq.mm to 35 sq.mm & Outer Sheathing
SPL-VTEK-606T	RoHS Compliance Automotive Cable Compound (T2)	Class B as per ISO 6722, Temp Rating : -40°C to 105°C	Automotive Cable with 0.35 sq.mm to 25 sq.mm & Outer Sheathing
SPL-VTEK-602/01	RoHS Compliance Automotive Cable Compound (T2)	Class B as per ISO 6722, LV 112 Temp Rating : -40°C to 105°C	Automotive Cable with 0.35 sq.mm to 4.0 sq.mm
SPL-VTEK-125T	RoHS Compliance Automotive Cable Compound (T3)	Class C as per ISO 6722 Temp Rating : -40°C to 125°C	Automotive Cable with 0.35 sq.mm to 6.0 sq.mm
* Available in RoHS version also.

ESCONTEK ^R

SEMI- Conductive Compound

Semi conductive Thermoplastic & Crosslinkable Compound for MV & HV Cable

SEMICONDUCTING COMPOUND - (THERMOPLASTIC)

SEMICONDUCTING COMPOUND - (PEROXIDE CROSS-LINKABLE)

SEMICONDUCTING COMPOUND - (SKIN COATING)

Grade	Description	Standard	Application	Download
SP-PESC-11	Excellent Heat Deformation Resistant for Conductor & Insulation Shielding	ICEA - S-66-524 / NEMA WC7, BS 6622, IEC-60502	Medium Voltage Power Cable

PE Sheathing

Polyethylene Compound

PE Based Medium Density/High Density Sheathing Compound For Power Cable Application.

POLYETHYLENE COMPOUND

TRACK RESISTANCE SHEATHING COMPOUNDS FOR MVCC

Grade	Description	Standard	Application
SPP-05-CA	Environmental Stress Crack Resistance (ESCR) & Weather Resistance LLDPE Compound	BS-6234 :TYPE 03C,TS1, ASTM D 1248,TYPE 2, Class C CAT-5,Grade E5,J3	Telephone & Power Cable Sheathing
SPL-MD	Black/Natural MDPE compound with ESCR and heat deformation properties	IS 7098 (Part-Ill) 1993, ASTM D 1248, CLASS C, Category 5, Grade E8, E9,J4, BS 6234, Type 03C, TS2,IEC - 60502, Type ST7, IEC - 60840, Type ST7	Power & Communication Cable Sheathing
HTP-HDS	HDPE Sheathing Compound with Excellent ESCR and Heat Deformation Properties	BS-6234 :Type H03C, TS2,ASTM D 1248, Type-Ill, Class C CAT-5, Grade EB, E9,J4	Optical Fibre & Communication Cable / Power Cable
HTP-HD-TR	Excellent TRACK RESISTANCE HDPE Sheathing Compound	ASTM D 2303	Jacketing of Optical Fibre Cable for HV Power Transmission lines
HTP-HD-TR 23	TRACK RESISTANCE HOPE Sheathing Compound (Carbon black content 2.3%)	ASTM D 2303	Jacketing of telecom & Optical Fibre Cable
HTP-HDS-HMW	High molecular weight PE Sheathing Compound	ASTM D 124B, Type-Ill, Class C CAT-5, Grade E 11, E9,J5	Single Insulation Telephone & Sheathing of Various Cables including Jelly Filled Copper Cable

SILICONE COMPOUNDS

Grade	Description	Standard	Application	Download
SPL-SIGP-03	Silicone Rubber Compound (150°C)	IE 5 to IS 6380	Insulation of Heat Resistant Cable
SPL-SiFr-02	Ceramifiable Silicone Rubber Compound (180°C)	El 2 to BS EN 50363-1	Insulation of Fire Resistant Cable
